| 大小问题 | 尺寸mm | ||||||||
| D级 | d级 | d1 | D2 | d2 | 3 | L级 | L2 | L3 | |
| CLQU-1/4 | 17(0.67) | 6.4(0.25) | 3.9(0.15) | 17(0.67) | 6.4(0.25) | 3.9(0.15) | 44.8(1.76) | 17(0.67) | 17(0.67) |
| CLQU3/8 | 23(0.91) | 9.7(0.38) | 6.5(0.26) | 17(0.67) | 6.4(0.25) | 3.9(0.15) | 501.97 | 20(0.79) | 17(0.67) |
| CLQU3/8 | 23(0.91) | 9.7(0.38) | 6.5(0.26) | 23(0.91) | 9.7(0.38) | 6.5(0.26) | 52.82.08 | 20(0.79) | 20(0.79) |
| CLQU-1/2 | 30(1.18) | 12.7(0.5) | 9.6(0.38) | 23(0.91) | 9.7(0.38) | 6.5(0.26) | 54.2(2.13) | 23(0.91) | 20(0.79) |
| CLQU-1/2 | 30(1.18) | 12.7(0.5) | 9.6(0.38) | 30(1.18) | 12.7(0.5) | 9.6(0.38) | 57.6(2.27) | 23(0.91) | 23(0.91) |
| CLQU3/4 | 40.61.6 | 19(0.75) | 15.8(0.62) | 23(0.91) | 9.7(0.38) | 6.5(0.26) | 61.5(2.42) | 33(1.3) | 20(0.79) |
| CLQU3/4 | 40.61.6 | 19(0.75) | 15.8(0.62) | 30(1.18) | 12.7(0.5) | 9.6(0.38) | 64.5(2.54) | 33(1.3) | 23(0.91) |
| CLQU3/4 | 40.61.6 | 19(0.75) | 15.8(0.62) | 40.61.6 | 19(0.75) | 15.8(0.62) | 72.6(2.86) | 33(1.3) | 281.1 |
| CLQ1U1X3/8 | 491.93 | 25.4(1) | 222.0.87 | 23(0.91) | 9.7(0.38) | 6.5(0.26) | 662.6 | 37(1.46) | 20(0.79) |
| CLQ1U1X1/2 | 491.93 | 25.4(1) | 222.0.87 | 30(1.18) | 12.7(0.5) | 9.6(0.38) | 69(2.72) | 37(1.46) | 23(0.91) |
| CLQ1U1X3/4 | 491.93 | 25.4(1) | 222.0.87 | 40.61.6 | 19(0.75) | 15.8(0.62) | 74.1(2.92) | 37(1.46) | 281.1 |
| CLQ1-U-1X1 | 491.93 | 25.4(1) | 222.0.87 | 491.93 | 25.4(1) | 222.0.87 | 80.7(3.18) | 37(1.46) | 321.26 |
